Features
1. The whole machine bed of the CNC
vertical machining center is cast by HT250-300 high strength resin bonded sand
with aging treatment, fixed column support, cross slide carriage, the L type
movable work table, firm foundation and stable frame.
2. The X, Y and Z axis of the CNC vertical machining center are linear rolling
guide, noise free, micro friction, sensitive dynamic response, stable accuracy,
meeting the requirement of accuracy and production in enormous quantities.
3. The servo feed is a digital alternating current servo motor, high accuracy
rolling screw transmission, pre-drawing frame so the rigidity is strengthened
and the thermal deformation is offset.
4. Barrel type spindle unit, integral installation, convenient and swift for
maintenance.
5. The spindle of the CNC vertical machining center is disposed with location
programmer with accurate pointing and rigid tapping function.
6. The stable and reliable ATC system can be disposed with swash plate type
tool magazine.
7. The CNC vertical machining center uses the imported rolling screw and NSK,
SKF and FAG spindle bearing and screw bearing. It uses superior components to
ensure the reliability of the machine. The machine is disposed with chip
removal and coolant system, and the protection system is designed with the
Pro/E software.
Technical Specifications
Model |
RFSV105 |
||
Table |
Table size |
mm |
1250×550 |
Bearing
capacity |
kg |
1000 |
|
T-slot |
mm |
5×18×100 |
|
Travel |
X-axis |
mm |
1050 |
Y-axis |
mm |
600 |
|
Z-axis |
mm |
630 |
|
Spindle Center
to Way Cover |
mm |
600 |
|
Spindle Nose
to Table Top |
mm |
160~790 |
|
Feed |
Rapid feed
rates ( X/Y/Z ) |
m/min |
24/24/24
(36/36/30 OPT.) |
Feed rates |
mm/min |
1~10000 |
|
Motor power
(X/Y/Z) |
N.m |
12/12/12 |
|
Spindle |
Spindle speed |
rpm |
8000
6000/10000 OPT) |
Spindle taper |
/ |
ISO40 (ISO50
OPT) |
|
Spindle motor |
kw |
7.5/11(11/15
Opt.) |
|
Spindle front
Dia. |
mm |
Ф70 |
|
Auto tool
exchanger |
Tool Magazine
Capacity |
Nos. |
24 |
Max. Tool
Diameter |
mm |
Ф76/Ф150 |
|
Max. Tool
Length |
mm |
300 |
|
Max. Tool
Weight |
kg |
7 |
|
Others |
Hydraulic
Pressure |
Mpa |
OPT |
Pneumatic
Pressure |
Mpa |
0.5~0.8 |
|
Cooling System |
/ |
Nozzle + chip
flush |
|
Chip Removal |
/ |
Automatic chip
conveyor (optional) |
|
Protection |
/ |
Fully |
|
Machine
Dimensions |
mm |
4200×2600×3000 |
|
Weight |
kg |
8000 |
|
Positioning
Accuracy |
mm |
0.01 |
|
Repeatability |
mm |
0.005 |
|
CNC system |
/ |
Standard FANUC
oi, optional: MITSUBISHI E68, MITSUBISHI 64M, SIEMENS, etc. |
